The common parameters of workshop isolation fence

The common parameters of workshop isolation nets typically involve materials, dimensions, structure, surface treatment, and other aspects, depending on the usage scenario and safety requirements. Below is a classification of the main parameters:

—

**1. Material Parameters**
- **Material Type**: Common materials include low-carbon steel wire, stainless steel wire, galvanized steel wire, aluminum alloy, etc., with varying corrosion resistance and strength.
- **Surface Treatment**: Such as electro-galvanizing, hot-dip galvanizing, powder coating (PVC coating), and plastic dipping, which affect corrosion resistance and appearance.

—

**2. Mesh Specifications**
- **Mesh Shape**: Square, diamond (chain-link mesh), rectangular, etc.
- **Mesh Size**: Common ranges include 50×50mm, 50×100mm, 75×150mm, etc., selected based on protection needs (e.g., small mesh for preventing small object drops).

—

**3. Panel Dimensions**
- **Height**: Standard heights range from 1.0m to 3.0m (customizable for taller requirements).
- **Width**: Single panel widths are typically 1.5m to 3.0m, facilitating transportation and installation.

—

**4. Wire Diameter**
- **Wire Diameter**: Ranges from 3.0mm to 6.0mm; thicker wires offer higher strength.
- **Frame Pipe**: Frame square pipes commonly use 20×20mm, 30×30mm, or larger, with thicknesses of 1.0mm to 2.5mm.

—

**5. Post Parameters**
- **Post Material**: Typically galvanized steel pipes, square tubes, or round tubes.
- **Post Dimensions**: Such as 50×50mm square tubes or φ60mm round tubes, with wall thicknesses of 1.2mm to 3.0mm.
- **Post Spacing**: Generally 2.0m to 3.0m, designed based on panel width and wind resistance.

—

**6. Installation Method**
- **Fixing Method**: Embedded (depth typically 30cm to 50cm), flange bolt fixing (for hardened ground), or expansion screw fixing.
- **Connectors**: Anti-theft bolts, clips, or welding.

—

**7. Performance Parameters**
- **Impact Resistance**: Designed to meet protection level standards (e.g., EN ISO 1461).
- **Load Capacity**: Customized for specific needs (e.g., anti-climbing, anti-crushing).
- **Corrosion Resistance Life**: Hot-dip galvanizing can last over 20 years, while powder coating lasts about 5–10 years (depending on the environment).

—

**8. Appearance Parameters**
- **Color**: Common colors include green, gray, yellow, black, etc., with customizable powder coating colors (e.g., RAL color chart).
- **Light Transmittance**: Mesh size and structure affect visibility and transparency.

—

**9. Accessory Parameters**
- **Anti-Theft Design**: Such as tamper-proof bolts or lockable door frames.
- **Door Configuration**: Options include single or double doors, with widths of 1.0m to 2.0m.
- **Top Design**: Optional additions like barbed wire or razor mesh for enhanced protection.

—

**10. Application Scenario Parameters**
- **Workshop Type**: Machinery processing workshops, storage areas, hazardous equipment isolation zones, etc.
- **Protection Level**: General isolation, splash protection, anti-climbing, fire resistance (requires flame-retardant materials).

—

**Purchasing Recommendations**
- **Environmental Factors**: Choose hot-dip galvanized or stainless steel materials for humid, high-temperature, or corrosive environments.
- **Safety Standards**: Refer to local industry standards (e.g., Chinese standard GB/T 34394-2017 for fencing nets).
- **Customization Needs**: Non-standard sizes or special features (e.g., acrylic panels combined with metal mesh) require communication with suppliers.

By matching parameters to specific needs, a balance between cost and performance can be achieved, ensuring the safety, durability, and functionality of the isolation net.
